Name: 4.061 Combination roller bearing Combined Bearings
Brand: Changzhou Suma Precision Machinery Co., Ltd
SKU: 4.061
Price: 21.00 USD
Availability: InStock

خانه محصولات نوع یوغ مسیر غلتک

4.061 Combination roller bearing Combined Bearings

جزئیات محصول:

محل منبع:	چین
نام تجاری:	SUMA
گواهی:	ISO SGS
شماره مدل:	4.061

پرداخت:

مقدار حداقل تعداد سفارش:	1
قیمت:	USD20-USD23 PER PIECE
جزئیات بسته بندی:	جعبه کارتن
زمان تحویل:	2-5 روز
شرایط پرداخت:	L/C، D/A، D/P، T/T، Western Union، Paypal
قابلیت ارائه:	100000 قطعه در ماه

مخاطب

توضیحات محصول جزئیات

نام محصول:	غلتک ترکیبی	مواد:	بلبرینگ فولاد GCR15
SIZE:	509032 میلی متر	دین ظرفیت بار:	10000
استا ظرفیت بار:	161000	بسته:	بسته رول + جعبه کارتن
گارانتی:	6 ماه	OEM:	قبول کنید

4.061 Combination roller bearing Combined Bearings

Description of Combined Roller Bearing for Forklift

The Combined Roller Bearing is composed of two main rollers, a side roller and a shaft head, which are installed in two different directions to reduce space and reduce manufacturing costs. The radial and axial direction bearing capacity is relatively large, and the accessories are highly replaceable. The adjustable combined roller bearing can adjust the position of the mandrel by adjusting the eccentric outer hexagon or the eccentric valve to achieve the purpose of adjusting the axial dimension of the side roller.

Composite roller bearings are mainly used in: forklifts, stackers, metallurgical industry, container front forks, cranes and other large lifting equipment and material lifting equipment.

Catalogue of Combined Roller Bearings for Forklift

4.061 Combination roller bearing Combined Bearings 0

Model No.	D mm.	T mm.	d -0.05 mm.	H mm.	h mm.	B mm.	A mm.	S mm.	r mm.	C KN	COKN	COAKN	r/pm max.	Weight kg
4.053	52,5	40	30	33,0	27,0	17	5,0	15	2	24,0	32,0	7	800	0,46
4.054	62,5	42	30	37,5	30,5	20	2,5	20	3	31,0	35,5	11	900	0,53
4.055	70,1	48	35	44,0	36,0	23	2,5	22	4	45,5	51,0	14	900	0,80
4.056	77,7	54	40	48,0	36,5	23	3,0	26	4	48,0	56,8	18	800	1,00
4.057	77,7	53	40	40,0	29,0	23	3,0	26	4	48,0	56,8	18	800	0,87
4.058	88,4	59	45	57,0	44,0	30	3,5	26	3	68,0	72,0	23	750	1,62
4.059	101,2	67	50	46,0	33,0	28	3,0	30	3	73,0	82,0	27	700	1,74
4.06	107,7	71	55	54,0	39,0	31	3,0	34	5	81,0	95,0	36	650	2,27
4.061	107,7	71	60	69,0	55,0	31	4,0	34	5	81,0	95,0	36	650	2,82
4.062	123,0	80	60	72,3	56,0	37	5,0	40	5	110,0	132,0	50	550	3,89
4.063	149,0	103	60	78,5	58,5	43	5,5	50	3	151,0	192,0	71	450	6,52
